A Line of Light,
Not Just a Point.
Solid core side glow fiber releases light continuously along its entire length instead of at a single tip — a soft, even glowing line driven from one remote illuminator, in eleven diameters from fine detailing to bold linear accents.
Where end glow fiber concentrates light at a single tip, Nucleo's NL-SOF solid core side glow fiber is engineered to leak light steadily along its entire length — the polymer core scatters the internal light outward rather than trapping it. The result reads like a glowing rope or neon line rather than a series of points, and like all Nucleo fiber it is driven from a remote illuminator, keeping heat and electronics away from the finished surface entirely.
From fine 1.5mm detailing lines to a bold 14mm feature strand, all supplied in 100m rolls on the same illuminator platform.
1.5mm
2mm
2.5mm
3mm
4mm
5mm
6mm
8mm
10mm
12mm
14mm
A different optical behaviour from end glow fiber, suited to linear rather than point applications.
Continuous Line Glow
Light releases evenly along the run instead of at a single point, producing a soft, rope-like glowing line.
Eleven Diameters
1.5mm to 14mm covers fine decorative detailing through to bold, highly visible feature strands.
100m Rolls
Consistent roll length across the range simplifies quantity planning for linear runs of any diameter.
Polymer Core Construction
Purpose-built polymer, distinct from the PMMA used in end glow fiber, engineered specifically for side-emission behaviour.
Flexible & Bendable
Can be curved around corners and shapes for signage outlines, coving lines and decorative silhouettes.
No Electronics in the Run
The glowing line itself carries no current — only the remote illuminator connects to mains power.
Colour Set at the Illuminator
Since colour comes from the light source, the entire run can be changed to any colour the connected illuminator supports.
Stocked & Dispatched from Mumbai
Standard roll lengths ship within 24–48 hours; project volumes are coordinated against your installation schedule.
| Model | Diameter | Length / Roll | Material | PVC Sheath | Colour |
|---|---|---|---|---|---|
| NL-SOF-1.5 | 1.5mm | 100m | Polymer | No | Transparent |
| NL-SOF-2 | 2mm | 100m | Polymer | No | Transparent |
| NL-SOF-2.5 | 2.5mm | 100m | Polymer | No | Transparent |
| NL-SOF-3 | 3mm | 100m | Polymer | No | Transparent |
| NL-SOF-4 | 4mm | 100m | Polymer | No | Transparent |
| NL-SOF-5 | 5mm | 100m | Polymer | No | Transparent |
| NL-SOF-6 | 6mm | 100m | Polymer | No | Transparent |
| NL-SOF-8 | 8mm | 100m | Polymer | No | Transparent |
| NL-SOF-10 | 10mm | 100m | Polymer | No | Transparent |
| NL-SOF-12 | 12mm | 100m | Polymer | No | Transparent |
| NL-SOF-14 | 14mm | 100m | Polymer | No | Transparent |
Anywhere a continuous glowing line is needed rather than a field of individual points.
Ceiling & Wall Coving Lines
A soft linear glow traced along cove details as a heat-free alternative to LED strip in sensitive locations.
Signage Outlines
Channel-set fiber traces letterforms and logo outlines with an even, continuous glow.
Event & Stage Decor
Lightweight and heat-free, side glow fiber outlines set pieces, arches and backdrops for events.
Pool Edge & Waterline Accents
Traces the perimeter of a pool or water feature with the illuminator kept safely outside the wet zone.
Automotive Interior Trim
Fine diameters set into dashboards and door trims for ambient interior lighting lines.
Retail Display Edging
Outlines shelf edges and display plinths with a soft glow that changes colour with the illuminator.
Festive & Seasonal Displays
Flexible enough to shape into decorative motifs for seasonal storefronts and installations.
Art Installations
Artists and exhibition designers use the continuous glow line as a heat-free, flexible medium for light-based work.
Enquire About Side Glow Fiber Optic Cable
Our team helps you match diameter, run length and illuminator output for an even, continuous glow line.
