One Feed In.
A Cluster of Points Out.
The NL-SSOF series bundles 1, 3 or 7 individual fiber strands into a single cable run from the illuminator, then separates into a tight cluster of light points at the working end — built for compact, closely-grouped point effects.
Running a separate single-strand fiber to every individual point in a small cluster adds unnecessary cable bulk. Nucleo's NL-SSOF series solves this by bundling 1, 3 or 7 strands of 0.75mm or 1.0mm PMMA fiber into a single manageable cable for the length of the run, then letting the strands separate and terminate individually once they reach the display area — giving a compact group of light points from one connection back to the illuminator.
Choose the strand count based on how many closely-grouped points the installation needs from a single feed.
1-Strand
A single point of light. Available bare or with a PVC-jacketed run for added protection.
3-Strand
Three points from one feed — suited to small clustered accents and compact garland sections.
7-Strand
Seven points from a single cable run — the densest cluster in the series, for tighter groupings of light.
A different job to single-strand end glow fiber — this series is about grouping several points close together without cable clutter.
Bundled Multi-Strand Construction
1, 3 or 7 individual PMMA strands travel together as one cable, then separate into individual points at the working end.
0.75mm & 1.0mm Strand Diameters
Two strand sizes across the range let you fine-tune point brightness and density.
Bare & PVC-Jacketed Options
Bare 1-strand variants suit short protected runs; jacketed variants across the range add mechanical protection for longer or more exposed routing.
Reduces Cable Clutter
One cable run replaces multiple individual strands back to the illuminator, simplifying routing for closely-grouped points.
Trimmable at the Termination End
Individual strand tails can be trimmed to set the exact point spacing needed once the bundle reaches its display area.
Point-Source Glow Per Strand
Each strand behaves like an individual end glow fiber, producing a crisp point rather than a diffuse glow.
Standard Illuminator Compatibility
Connects to the Nucleo NLE fiber light engine range — confirm total strand count for correct illuminator sizing.
Stocked & Dispatched from Mumbai
Standard lengths ship within 24–48 hours; project volumes are coordinated against your installation schedule.
| Model | Inner Dia. | Outer Dia. | Length / Roll | PVC Sheath | Colour |
|---|---|---|---|---|---|
| NL-SSOF-1×0.75 | 0.75mm | 0.75mm | 2700m | No | Transparent |
| NL-SSOF-1×1.0 | 1mm | 1mm | 1500m | No | Transparent |
| NL-SSOF-1×0.75 (Jacketed) | 0.75mm | 1.5mm | 2700m | Yes | Transparent |
| NL-SSOF-1×1.0 (Jacketed) | 1mm | 1.8mm | 1500m | Yes | Transparent |
| NL-SSOF-3×0.75 | 3×0.75mm | 3mm | 1350m | Yes | Transparent |
| NL-SSOF-3×1.0 | 3×1.0mm | 3.5mm | 900m | Yes | Transparent |
| NL-SSOF-7×0.75 | 7×0.75mm | 4mm | 450m | Yes | Transparent |
Anywhere several points need to sit close together without running multiple cables back to the illuminator.
Decorative Garlands
Clustered points threaded through garlands and drapes for compact, closely-spaced sparkle effects.
Craft & Costume Work
Small groups of light points woven into costumes, props and craft pieces where a single feed keeps wiring manageable.
Small Feature Displays
Compact retail and exhibition displays that need a tight group of points rather than a dispersed field.
Automotive Interior Accents
Grouped points for headliners, dashboards and interior trim clusters in vehicle projects.
Table & Centrepiece Lighting
Small clusters of point light for event centrepieces and table settings, run from a single hidden illuminator.
Costume & Stage Props
Multi-point bundles integrated into performance costumes and props without bulky individual cabling.
Novelty & Gift Items
Compact point clusters for decorative novelty products and gift displays.
Festive Decor Clusters
Grouped sparkle points for festive installations where several closely-set points are needed per fixture location.
Enquire About Side Spot Light Fiber Optic Strings
Our team helps you choose the right strand count, diameter and illuminator for your point cluster.
